Sunsynk 8kW 1P Inverter (LV)(New Gen) + Sunsynk 5,12 kWh G Series + 16 Canadian Solar Panels
Couldn't load pickup availability
Sunsynk 8kW 1P LV Hybrid Inverter (New Gen) + Sunsynk 5.12kWh G Series Battery + 16 Canadian Solar Panels
Product Name
Sunsynk 8kW 1P LV Hybrid Inverter (New Generation) + Sunsynk 5.12kWh G Series Lithium Battery + 16× Canadian Solar Panels
Model
• Inverter: SYK-SG04LP1-8KW-L (New Gen)
• Battery: Sunsynk G Series 5.12kWh (51.2V)
Includes:
Sunsynk 8kW Inverter (2025 Model) X1
Sunsynk 5,12kW G-Series Battery X1
Canadian Solar Panels 600w-620w X16
Complete Aluminium Mounting Structure For IBR/Corrugated Roof Types X16
250A Battery Fuse Disconnector X1
Brand
Sunsynk
Type
Complete Solar Power Kit (Hybrid Inverter + Lithium Battery + Solar Panels)
Key Features
Sunsynk 8kW 1P LV Hybrid Inverter (New Gen)
-
Single-phase, low-voltage hybrid inverter
-
High efficiency power conversion with upgraded Gen-2 hardware
-
Supports solar, battery, grid, and generator integration
-
Dual MPPT with wide PV input range
-
Real-time monitoring through Sunsynk Connect app
-
UPS-level switching for essential loads
-
Built-in protections (over-voltage, over-current, anti-islanding)
Sunsynk 5.12kWh G Series Lithium Battery
-
5.12kWh high-performance LiFePO₄ module
-
Long cycle life with intelligent BMS
-
Supports parallel expansion
-
Compact wall-mount or rack-mount flexibility
-
Stable LFP chemistry for maximum safety
Canadian Solar Panels (x16)
-
Premium Tier-1 monocrystalline modules
-
High efficiency and strong low-light performance
-
Suitable for residential or small commercial PV systems
Specifications
Inverter Specifications
| Parameter | Value |
|---|---|
| Rated Power | 8kW |
| Phase | Single-phase |
| Battery Type | 48V Lithium (LV) |
| MPPT Trackers | 2 |
| Max PV Voltage | 500V |
| Communication | WiFi / RS485 / CAN |
| Application | Hybrid – Solar + Battery + Grid |
Battery Specifications
| Parameter | Value |
|---|---|
| Usable Energy | 5.12kWh |
| Nominal Voltage | 51.2V |
| Chemistry | LiFePO₄ |
| Cycle Life | >6000 cycles |
| Modularity | Parallel expansion supported |
| Communication | CAN / RS485 |
Quality & Support
This bundle combines Sunsynk’s latest-generation 8kW LV hybrid inverter with a dependable G Series 5.12kWh lithium battery and high-quality Canadian Solar panels. Designed for reliability, fast installation, and long-term performance, the system is ideal for homes needing robust power output with room for expansion. Full warranty and technical support included.
We Don’t Just Beat Quotes — We Build Better Systems.
Our certified installers design each PV setup for maximum performance and long-term reliability. Every installation is backed by full warranty support and genuine spare parts, ensuring your investment delivers power — and peace of mind — for years to come.
