Key Features:
• Hybrid functionality: Integrates solar, battery, grid, and generator power.
• Dual MPPT design: Optimizes solar energy with two trackers (2 strings each).
• Scalable: Supports grid-tied, off-grid, or hybrid setups with expandable configurations.
• High efficiency: Up to 97.6% with 80% self-consumption ratio.
• Smart monitoring: Remote control and monitoring via app or interface.
• Grid-tie support: Feeds excess power to the grid for net metering.
Specifications:
• Power Output: 8,000W (continuous and backup).
• PV Input: 12,800W max, 500V max voltage, 26A per MPPT.
• Battery Compatibility: 48V lithium-ion (LiFePO4) or lead-acid.
• Efficiency: 97.6% max, DC/AC ratio up to 1.3.
• Weight: 32kg
• Protection: IP65 (weather-resistant), multiple safety features (e.g., overvoltage, short-circuit protection).
