Key Features:
• Hybrid Functionality: Integrates solar, battery, grid, and generator power for optimized energy management.
• Twin MPPT Technology: Dual MPPTs (2 strings each) maximize solar energy harvest across varying conditions.
• Flexible Compatibility: Supports conventional PV, wind turbines, micro-inverters, and 48V LiFePO4 batteries.
• Smart Monitoring: Sunsynk Connect platform enables full control, visibility, and customization via Wi-Fi.
• Scalable Design: Supports up to 6 units in parallel and expandable battery storage (SUN-L5.12 compatible).
• Plug and Play: In-built connection points (Load, Grid, CT, Wi-Fi) and wall-mount bracket for easy installation.
Specifications:
• Power Output: 3,600W continuous, 7,200VA peak.
• PV Input: 4,500W max DC input, 500V max voltage, 125-425V MPPT range, 12A total input current (2 MC4 sets combined).
• Battery Parameters: 51.2V nominal voltage, 43.2-57.6V range, 60A max charge/discharge current (configurable).
• Efficiency: Up to 97.6% max, 99.9% MPPT efficiency.
• Output Voltage/Frequency: 220/230/240V single-phase, 50/60Hz (configurable).
• Protection: IP41, anti-islanding, PV lightning, and leakage current protection.
• Warranty: 10 years (requires registration within 7 days of commissioning).
