Key Features:
• Hybrid Functionality: Seamlessly manages power from solar panels, batteries, grid, and generators for optimized energy use.
• Twin MPPT Technology: Dual Maximum Power Point Trackers (2 strings each) maximize solar energy harvest across varying conditions.
• Flexible Compatibility: Supports conventional PV, wind turbines, micro-inverters, and both lithium-ion and lead-acid batteries (48V).
• Smart Energy Management: Prioritizes solar power, reduces grid reliance, and supports real-time monitoring via a mobile app.
• Scalable Design: Suitable for on-grid, off-grid, or hybrid setups with expandable configurations.
• Robust Protection: Includes overload, overvoltage, short-circuit protection, and IP41 ingress protection for reliable operation.
Specifications:
• Power Output: 8,000W continuous, 16,000VA peak.
• PV Input: 10,000W max DC input power, 500V max voltage, 120-450V MPPT range, 23A x 2 max input current.
• Battery Parameters: 48V nominal voltage, 40-60V range, 150A max charge current, 180A max discharge current, 100-2000Ah capacity.
• Efficiency: Up to 97.6% with a DC/AC ratio of 1.3.
• Output Voltage/Frequency: 220/230/240V single-phase, 50/60Hz (configurable).
• Protection: IP41, anti-islanding, PV lightning, and leakage current protection.
• Warranty: Standard 5 years, extendable to 10 years with Sunsynk batteries (if registered within 7 days of commissioning).
