Sunsynk 5,12 kWh Li-Ion Battery 51,2V G Series
Couldn't load pickup availability
🔋 Sunsynk 5.12 kWh Li‐Ion Battery 51.2 V G Series
Model: G5.12
Brand: Sunsynk
Type: Modular Wall / Rack-Mounted LiFePO₄ (Lithium Iron Phosphate) Energy Storage System
⚡ Key Features
-
Usable energy capacity of 5.12 kWh, suitable for residential solar storage or backup applications.
-
Nominal voltage of 51.2 V, compatible with 48-V hybrid inverter systems.
-
Advanced LiFePO₄ chemistry for enhanced safety, long lifespan and thermal stability.
-
Modular design—install one unit, or scale up by adding additional modules to expand capacity.
-
Compact wall or rack mount installation, optimized for space and ease of use.
-
Built-in Battery Management System (BMS) offering protection against overcharge, deep discharge, over‐current and temperature extremes.
📐 Specifications
| Specification | Value |
|---|---|
| Model | G5.12 |
| Usable Energy Capacity | 5.12 kWh |
| Nominal Voltage | 51.2 V |
| Battery Chemistry | LiFePO₄ (Lithium Iron Phosphate) |
| Nominal Capacity (Ah) | ~100 Ah |
| Scalability | Modular/Parallel units supported |
| Dimensions (approx.) | ~450 × 150 × 533 mm |
| Net Weight (approx.) | ~45 kg |
| Warranty | Standard Sunsynk warranty terms |
🏷️ Quality & Support
Sunsynk’s G Series battery systems are designed for modern homes seeking reliable, efficient energy storage. Built for local installation, these units offer smart integration with solar PV, solid after-sales service and capacity to upgrade as your energy needs grow.
