🔋 Hubble AM16 PLUS 16kWh Lithium Battery
Brand: Hubble Lithium
Model: AM16 PLUS
Type: Low-Voltage LiFePO₄ Battery Energy Storage System
Application: Residential & Commercial Solar, Backup & Off-Grid Energy Storage
⚡ Key Features
- 16.1kWh energy capacity provides long-lasting backup power for residential and commercial energy storage systems.
- 314Ah LiFePO₄ prismatic cells deliver exceptional safety, reliability, and long service life.
- Integrated Hubble Cloudlink enables 24/7 remote monitoring and real-time battery performance tracking.
- Advanced Battery Management System (BMS) protects against overcharge, over-discharge, over-current, short circuit, and over/under-temperature conditions.
- Unlimited cycle warranty for 10 years (Terms & Conditions apply) for outstanding long-term value.
- Supports up to 15 batteries in parallel with full communication for scalable energy storage systems.
- Intelligent current limiting automatically regulates charging current to protect the battery.
- Informative RGB LED display strip provides clear battery status and state-of-charge indication.
- Low self-discharge ensures stored energy is retained for longer periods.
- Excellent high-temperature performance delivers reliable operation in demanding environments.
- Lockable wheels and low centre-of-gravity design allow safe placement and easy mobility.
- Compatible with leading inverter brands through CAN Bus, RS485, and RS232 communication.
📐 Technical Specifications
| Specification | Value |
|---|---|
| Model | AM16 PLUS |
| Battery Chemistry | LiFePO₄ (Lithium Iron Phosphate) |
| Nominal Voltage | 51.2V DC |
| Rated Capacity | 314Ah |
| Battery Energy | 16.1kWh |
| Maximum Continuous Charge Current | 130A |
| Maximum Continuous Discharge Current | 157A |
| Recommended Inverter Cut-Off Voltage | 49V |
| Minimum Inverter Cut-Off Voltage | 47V |
| Parallel Capability | Up to 15 Batteries |
| Communication | CAN / RS485 / RS232 |
| Monitoring | Integrated Hubble Cloudlink |
| Cell Type | LiFePO₄ Prismatic Cells |
| Cell Balancing | Passive Cell Balancing |
| Design Life | ±15 Years |
| Cycle Life | Unlimited Cycles (Within 10-Year Warranty Terms & Conditions) |
| Operating Temperature (Charging) | -10°C to 50°C |
| Storage Temperature | 10°C to 50°C |
| Humidity | 15% – 75% |
| Protection | Overcharge, Over-discharge, Over-current, Short Circuit, Over & Under Temperature |
| Certification | CE, UN38.3 |
| Enclosure | White Bake Lacquer Steel |
| Dimensions (H × W × D) | 970 × 500 × 260 mm |
| Weight | Approximately 131.5 kg |
🏡 Benefits
- High-capacity energy storage for demanding residential and commercial solar systems.
- Real-time cloud monitoring allows convenient remote system management.
- Modular design supports future expansion with up to 15 batteries connected in parallel.
- Advanced BMS and intelligent current limiting maximise battery safety and lifespan.
- Lockable wheels and floor-standing installation simplify positioning and maintenance.
- Long design life and unlimited cycle warranty provide exceptional long-term reliability.
- Compatible with a wide range of leading hybrid inverter brands for seamless system integration.
🏷️ Applications
- Residential solar battery storage
- Commercial energy storage systems
- Hybrid solar installations
- Off-grid power systems
- Backup power during load shedding
- Peak demand management and self-consumption optimisation
🏷️ Quality & Support
The Hubble AM16 PLUS 16kWh Lithium Battery combines high-capacity LiFePO₄ technology with intelligent battery management, integrated cloud monitoring, and industry-leading scalability. Designed for reliable long-term energy storage, it features advanced safety protection, excellent thermal performance, and seamless compatibility with leading inverter brands. Backed by Hubble's 10-Year Unlimited Cycle Warranty (Terms & Conditions apply), the AM16 PLUS is an ideal solution for residential and commercial solar energy storage systems.
