Dyness DL5.0F 5.12 kWh Battery
COMING SOON!
🔋 Dyness DL5.0F 5.12kWh Lithium Battery
Brand: Dyness
Model: DL5.0F
Type: Low-Voltage LiFePO₄ Battery Energy Storage System
Application: Residential Solar, Hybrid, Backup & Off-Grid Energy Storage
⚡ Key Features
- 5.12kWh nominal energy capacity for reliable backup power and daily solar energy storage.
- Advanced LiFePO₄ battery chemistry delivers exceptional safety, stability, and long service life.
- 95% Depth of Discharge (DoD) maximises usable battery capacity.
- Supports 1C continuous discharge for dependable high-power performance.
- Over 8,000 life cycles for outstanding long-term reliability.
- Compact 19-inch rack-compatible design for simple installation in standard battery cabinets.
- Integrated fire suppression system enhances operational safety.
- Built-in Wi-Fi monitoring enables convenient remote system management.
- Expandable up to 50 batteries in parallel for scalable residential and commercial energy storage.
- Compatible with leading hybrid inverter brands via CAN and RS485 communication.
- Backed by a 7-year standard warranty, extendable to 10 years (subject to Dyness warranty terms).
📐 Technical Specifications
| Specification | Value |
|---|---|
| Product Model | DL5.0F |
| Battery Chemistry | LiFePO₄ (Lithium Iron Phosphate) |
| Nominal Battery Energy | 5.12 kWh |
| Nominal Voltage | 51.2 V |
| Cycle Life | ≥8,000 Cycles |
| Protection Rating | IP20 |
| Expansion | Up to 50 Units in Parallel |
| Dimensions (W × D × H) | 345 × 548 × 146 mm |
| Net Weight | 41 kg |
🏷️ Certifications & Safety
- UN38.3
- CE-EMC
- CE-RED
- IEC 62619
- IEC 63056
- RoHS
- REACH
🏡 Benefits
- Maximises solar self-consumption while reducing electricity costs.
- Compact rack-mounted design saves installation space.
- High 95% usable capacity delivers more available energy.
- Long cycle life provides excellent return on investment.
- Modular design allows future battery expansion up to 50 units.
- Built-in Wi-Fi simplifies monitoring and system management.
- Advanced safety systems provide reliable long-term operation.
🏷️ Applications
- Residential solar battery storage
- Hybrid inverter systems
- Backup power during load shedding
- Off-grid solar systems
- Small commercial energy storage
- Rack-mounted battery installations
🏷️ Quality & Support
The Dyness DL5.0F 5.12kWh Lithium Battery is a compact, high-performance energy storage solution designed for residential and commercial solar applications. Built with premium LiFePO₄ cells, it offers 5.12kWh of energy storage, 95% usable capacity, over 8,000 operating cycles, integrated fire suppression, and built-in Wi-Fi monitoring. Its lightweight 19-inch rack-compatible design, combined with support for up to 50 batteries in parallel, makes it an excellent choice for scalable, reliable, and long-lasting energy storage systems.
Battery Specs difference to the older model
DATASHEET
