DYNESS BX51100 5.12kW LITHIUM-ION BATTERY
DYNESS BX51100 5.12kW LITHIUM-ION BATTERY
DYNESS BX51100 5.12kW LITHIUM-ION BATTERY
DYNESS BX51100 5.12kW LITHIUM-ION BATTERY
DYNESS BX51100 5.12kW LITHIUM-ION BATTERY
DYNESS BX51100 5.12kW LITHIUM-ION BATTERY

DYNESS BX51100 5.12kW LITHIUM-ION BATTERY

  • Sale
  • R 14,400.00
  • 9 available
Tax included.

  • esigned for residential and light commercial applications

  • Supports up to 30 units in parallel for scalable energy storage

  • Flexible installation options: wall-mounted, floor-standing, or stacked

  • Built-in Battery Management System (BMS) for enhanced safety

  • Compatible with leading inverter brands

  • Remote monitoring and firmware updates available via app

  • Compact design with a net weight of 50 kg

  • Protection level: IP20

  • Warranty: 10 years

General Data:

  • Battery Type: Lithium Iron Phosphate (LiFePO₄)

  • Nominal Voltage: 51.2V

  • Nominal Capacity: 100Ah

  • Energy Storage Capacity: 5.12kWh

  • Cycle Life: ≥6000 cycles

  • Weight: 50 kg

  • Dimensions (W × D × H): 558 mm × 545 mm × 150 mm

  • Operating Temperature Range: Charging: 0°C to 55°C; Discharging: -20°C to 55°C

  • Protection Level: IP20

  • Certification & Safety Standards: UN38.3, CE-EMC, IEC62619, CEI-021

Electrical Data:

  • Maximum Charge Current: 75A

  • Maximum Discharge Current: 75A

  • Peak Power Charge/Discharge Current: 100A (15s)

  • Recommended Charge/Discharge Current: 50A

  • Depth of Discharge (DOD): 90%

  • Operating Voltage Range: 44.8V to 57.6V

  • Nominal Battery Energy: 5.12kWh

Features:

  • High Energy Density – Compact and lightweight compared to lead-acid batteries

  • Long Lifespan – Up to 6000 cycles at 90% DOD

  • Built-in Battery Management System (BMS) – Protects against overcharge, over-discharge, overcurrent, and short circuits

  • Deep Cycle Performance – Supports full charge and discharge cycles without affecting battery health

  • Fast Charging Capability – Charges quicker than lead-acid batteries

  • Maintenance-Free – No need for water refilling or regular maintenance

  • Wide Operating Temperature Range – Performs efficiently in extreme temperatures

  • Eco-Friendly & Safe – Uses non-toxic LiFePO₄ chemistry, eliminating risks of thermal runaway and fire hazards

Applications:

  • Residential Solar Systems

  • Small Commercial Solar Installations

  • Backup Power Supply

  • Off-Grid Systems

  • Hybrid Solar Systems

  • Energy Storage for Load Shifting

  • Emergency Power Backup
