Colorful touch LCD, IP65 protection degree
AC couple to retrofit existing solar system
Max. 16 pcs parallel for on-grid and off-grid
operation; Support multiple batteries parallel
Max. charging/discharging current of 190A
6 time periods for battery charging/discharging
Support storing energy from diesel generator; ≤5 ms switchover time between modes
Zero-export / export-limiting function supported
Battery Input Data:
Battery Type : Lead-acid or Lithium-ion
Battery Voltage Range : 40–60V
Max. Charging/Discharging Current : 190A
Charging Strategy : Self-adaptation to BMS
Number of Battery Inputs : 1
PV String Input Data:
Max. PV Access Power : 14000W
Max PV Input Power : 12800W
Max PV Input Voltage : 500V
Start-up Voltage : 125V
MPPT Voltage Range : 125–425V
Number of MPPTs / Strings per MPPT : 2 / (2+2)
Max Input Current : 26A + 26A
Max Short-Circuit Current : 34A + 34A
AC Input/Output Data:
Rated AC Input/Output Active Power : 8000W
Max AC Input/Output Apparent Power : 8800VA
Rated AC Input/Output Current : 36.4/35A
Max AC Input/Output Current : 40/38.5A
Max Continuous AC Passthrough : 50A
