Colorful touch LCD, IP65 protection degree
Off-grid functionality (can operate fully independently or in hybrid mode)
AC couple to retrofit existing solar system
Max. 16 pcs parallel for on-grid and off-grid
operation; Support multiple batteries parallel
Max. charging/discharging current of 135A
6 time periods for battery charging/discharging
Support storing energy from diesel generator; ≤4 ms switchover time between modes
PV String Input Data:
Max. PV Access Power : 12000W
Max PV Input Power : 9600W
Max PV Input Voltage : 500V
Start-up Voltage : 125V
MPPT Voltage Range : 150–425V
Number of MPPTs / Strings per MPPT : 2 / (1+1)
Max Input Current : 18A + 18A
Max Short-Circuit Current : 27A + 27A
AC Input/Output Data:
Rated AC Input/Output Active Power : 6000W
Max AC Input/Output Apparent Power : 6600VA
Rated AC Input/Output Current : 27.3/26.1A
Max AC Input/Output Current : 30/28.7A
