Colorful touch LCD, IP65 protection degree
AC couple to retrofit existing solar system
Max. 16 pcs parallel for on‑grid and off‑grid operation; Support multiple batteries parallel
Max. charging/discharging current of 250 A
6 time periods for battery charging/discharging
Support storing energy from diesel generator
Hybrid functionality with UPS and peak‑shaving
PV String Input Data:
Max. PV Access Power : 20 000 W
Max PV Input Power : 16 000 W
Max PV Input Voltage : 500 V
Start‑up Voltage : 125 V
MPPT Voltage Range : 150–425 V
Rated PV Input Voltage : 370 V
Battery Input Data:
Battery Type : Lead‑acid or Lithium‑ion
Battery Voltage Range : 40–60 V
Max. Charging/Discharging Current : 250 A
Charging Strategy : Self‑adaptation to BMS
Number of Battery Inputs : 1
AC Input/Output Data:
Rated AC Input/Output Active Power : 10 000 W
Max AC Input/Output Apparent Power : 11 000 VA
Rated AC Input/Output Current : 45.5 A (in) / 43.5 A (out)
Max AC Input/Output Current : 50 A (in) / 47.9 A (out)
Max Continuous AC Passthrough : 60 A
