Slim and compact design, IP65 protection degree
Ideal for RVs, off-grid solar systems, backup power, and marine applications
Supports up to 4 units in parallel for increased capacity
Maintenance-free, no water refilling required
Lightweight and easy to transport
Built-in Battery Management System (BMS) for enhanced safety
Eco-friendly and safe, using non-toxic LiFePO₄ chemistry
General Data:
Battery Type: Lithium Iron Phosphate (LiFePO₄)
Nominal Voltage: 12.8V
Nominal Capacity: 100Ah
Energy Storage Capacity: 1.28kWh
Cycle Life: 3000 cycles at 100% Depth of Discharge (DOD)
Calendar Life: ≥6000 cycles at 80% DOD
Weight: ≈12–14kg
Dimensions (W × D × H): 330mm × 172mm × 214mm
Operating Temperature Range: Charging: 0°C to 50°C; Discharging: -20°C to 55°C
Protection Level: IP65
Certification & Safety Standard: UN38.3
Electrical Data:
Maximum Charge Current: 50A
Maximum Discharge Current: 100A
Nominal Voltage: 12.8V
Nominal Capacity: 100Ah
Energy Storage Capacity: 1.28kWh
Depth of Discharge (DOD): 100%
Maximum Charge Voltage: 14.6V
Discharge Cut-off Voltage: 10.8V
Features:
-
High Energy Density – Compact and lightweight compared to lead-acid batteries
-
Long Lifespan – Up to 3000 cycles at 100% DOD
-
Built-in Battery Management System (BMS) – Protects against overcharge, over-discharge, overcurrent, and short circuits
-
Deep Cycle Performance – Supports full charge and discharge cycles without affecting battery health
-
Fast Charging Capability – Charges quicker than lead-acid batteries
-
Maintenance-Free – No need for water refilling or regular maintenance
-
Wide Operating Temperature Range – Performs efficiently in extreme temperatures
-
Eco-Friendly & Safe – Uses non-toxic LiFePO₄ chemistry, eliminating risks of thermal runaway and fire hazards
Applications:
-
Recreational Vehicles (RVs)
-
Marine Use
-
Solar Power Systems
-
Backup Power Supply
-
Off-Grid Systems
-
Golf Carts and Electric Vehicles
-
Medical Devices
-
Outdoor and Camping Gear
